Dri3M240A railway panel indicator

Description

Triple indicator for railway applications.

General specifications

Availibility
Available with 90o pointer deflection as Dri3M240A, or with 240o pointer defelction as D3riM240S.

Sizes
Front 240 x 96 mm
Panel cut out 236 x 92 mm

Illumincation supply
24 VAC/DC, other voltage on request

Approx. consumption
2 W

Illumination type
LED

Input
4…20 mA, 0…20 mA, +/- 20 mA, +/- 10 V, 0…V other inputs on request

Accuracy
+ 1.5 % of full scale

Scale background
Black

Pointer and text
Yellow or white

Illumination
Green, red or yellow

Pointer illumination
Red or yellow
Other colours are on requesst

Operating temperature
-25 °C…+70 °C

Humidity
at 40 °C, max 95 %
