Description
Features
- High speed operation
- High burden
- Electrical reset contacts
- Independent hand reset flag
- 20 contacts
- Equivalent function to MVAJ24
- 2HSM516 specification
Application
The effect of a fault on a power system is dependent on the speed with which the fault can be detected & isolated. The 6RJ Series multi-contact high-speed trip relays are used for this isolating function roviding simultaneous tripping outputs.
A high speed coil provides fast operation( smaller than 12ms at nominal voltage including bounce), with specially constructed anti bounce buffers ensuring effective damping of the contacts to avoid excessive bounce.
