Rolling stock

  • D3a-136-B railway panel indicator

     Round panelmeter for railway applications, single pointer. General specifications Accuracy 1.5 % F.S.D. addirional 0.75 % / 10 °C Operating temperature -25 °C...+70 °C Humidity at 40 °C max. 95 % Protection IP54 rear IP50 (terminals IP00) Vibrations 5...150 Hz, 2 g random 3 x 5 h acc. EN 61373 (50155) Shock acc. EN 61373 Test voltage 2 kV Illumination LEDS, any voltage between 24 and 110 VAC/VDC Scale and…

  • D3a2-136-B railway panel indicator

     Round panelmeter for railway applications, double pointer.   General specifications Accuracy 1.5 % F.S.D. addirional 0.75 % / 10 °C Operating temperature -25 °C...+70 °C Humidity at 40 °C max. 95 % Protection IP54 rear IP50 (terminals IP00) Vibrations 5...150 Hz, 2 g random 3 x 5 h acc. EN 61373 (50155) Shock acc. EN 61373 Test voltage 2 kV Illumination LEDS, any voltage between 24 and 110 VAC/VDC Scale…

  • D3a85-B railway panel indicator

     Round panelindicator for railway applications, single pointer. General specifications Accuracy 1.5 % F.S.D. 0.75 % / 10 °C Operating temperature -25 °C...+70 °C Humidity at 40 °C max 95 % Protection Front IP54 Rear IP50 (terminals IP00) Vibrations 5...150 Hz, 2 g random 3 x 5 h acc. EN 61373 (50155) Shock According to EN 61373 Test voltage 2 kV Illumination LEDS, Any voltage between 24 V and 110 VAC/VDC…

  • D3v-144S-B railway panel indicator

     Square panelmeter for railway applications, single pointer. General specifications Accuracy 1.5 % F.S.D. 0.75 % / 10 °C Operating temperature -25 °C...+70 °C Humidity at 40 °C max. 95 % Protection front IP54 rear IP50 (terminals IP00) Vibrations 5...150 Hz, 2 g randaom 3 x 5 h acc. EN 61373 (50155) Shock acc. EN 61373 Test voltage 2 kV Illumination LEDS, any voltage between 24 and 110 VAC/VDC Scale and…

  • D3v2-144S-B railway panel indicator

     Square panelmeter for railway applications, double pointer. General specifications Accuracy 1.5 % F.S.D. 0.75 % / 10 °C Operating temperature -25 °C...+70 °C Humidity at 40 °C max. 95 % Protection front IP54 rear IP50 (terminals IP00) Vibrations 5...150 Hz, 2 g randaom 3 x 5 h acc. EN 61373 (50155) Shock acc. EN 61373 Test voltage 2 kV Illumination LEDS, any voltage between 24 and 110 VAC/VDC Scale and…

  • D3v2-96S-B railway panel indicator

     Square panelmeter for railway applications, double pointer. General specifications Accuracy 1.5 % F.S.D. 0.75 % / 10 °C Operating temperature -25 °C...+70 °C Humidity at 40 °C max. 95 % Protection front IP54 rear IP50 (terminals IP00) Vibrations 5...150 Hz, 2 g randaom 3 x 5 h acc. EN 61373 (50155) Shock acc. EN 61373 Test voltage 2 kV Illumination LEDS, any voltage between 24 and 110 VAC/VDC Scale and…

  • D3v72S-B railway panel indicator

     Square panelmeter for railway applications, single pointer. General specifications Accuracy 1.5% F.S.D. 0.75 % / 10 °C Operating temperature -25 °C...+70 °C Humidity at 40 °C max. 95 % Protection front IP54 rear IP50 (terminals IP00) Vibrations 5...150 Hz, 2 g random 3 x 5 h acc. EN 61373 (50155) Shock acc. EN 61373 Test voltage 2 kV Illumination Leds, any voltage between 24 and 110 VAC/VDC Scale and pointer…

  • D4-U200 relay module – 4 pole

     The D4-U200 relay module is a form, fit and function solution to replace all kind of contactors with a maximum of 4 contacts. The module consists of a 4-pole relay, spring clamp terminal connections and a housing to fasten the module. (more…)

  • D6-U200N-W Instantaneous relay, weld-no-transfer, 6 pole

     Plug-in safety critical railway relay with 6 weld-no-transfer single contacts. Also equipped with a back EMF suppression diode. No external retaining clip needed as integrated ‘snap-lock’ will hold relay into socket under all circumstances and mounting directions. The construction of the relay and choice of materials makes the D6-U200N-W relay suitable to withstand corrosive atmospheres, low and high temperatures, shock & vibration and dry to very humid environments. Compact design,…

  • D8-U200 relay – Plug-in, 8 pole

     Plug-in railway relay with eight change-over contacts. Standard equipped with a back EMF suppression diode and magnetic arc blow-out for high breaking capacity and long contact life. The construction of the relay and choice of materials makes the D8-U200 relay suitable to withstand corrosive atmospheres, low and high temperatures, shock & vibrating and dry to very humid environments. No external retaining clip needed as integrated ‘snap-lock’ will hold relay into…

  • D8-U200 relay module – 8 pole

     The D8-U200 relay module is a form, fit and function solution to replace all kind of contactors with a maximum of 8 contacts. The module consists of an 8-pole relay, screw or spring clamp terminal connections and a bracket to fasten the module. By applying the D8-U200 relay module all specifications of the standard D8-U200 relay are valid. The screw or spring clamp connections are made on the front panel…

  • D8-U200 relay module – 8 pole

     The D8-U200 relay module is a form, fit and function solution to replace all kind of contactors with a maximum of 8 contacts. The module consists of an 8-pole relay, screw or spring clamp terminal connections and a bracket to fasten the module. (more…)

  • D8M-U200 relay module

     The D8M-U200 relay module is a form, fit and function solution to replace all kind of (mini) contactors with a maximum of 8 contacts. The module consists of an 8-pole relay, spring clamp terminal connections and a bracket with surface/wall or 35 mm rail mounting. By applying the D8M-U200 relay module all specifications of the standard D8-U200 relay are valid. The spring clamp terminals provides 2 connection points per contact.…

  • Dd96S-B railway panel indicator

     Rectangle panemeter for railway applications. General specifications Accuracy 1.5 % F.S.D. addirional 0.75 % / 10 °C Operating temperature -25 °C...+70 °C Humidity at 40 °C max. 95 % Protection IP54 rear IP50 (terminals IP00) Vibrations 5...150 Hz, 2 g random 3 x 5 h acc. EN 61373 (50155) Shock acc. EN 61373 Test voltage 2 kV Illumination LEDS, any voltage between 24 and 110 VAC/VDC Scale and pointer Black…

  • DDK/DDJ Diode unit

     The DDK/DDJ diode unit consists of a D-relay housing containing 4/7 electrically isolated diodes. This gives the possibility to use them in different electrical circuits. (more…)

  • DGG-U200N Plug-in railway relay with 2 C/O contacts

     The DGG-U200N is the improved version of the DGG-U200 2-pole instantaneous relay.  The dimensions, pinning and specifications are identical but it is much more reliable switching very low currents (1 mA @ 5 VDC). It is therefore the perfect relay to switch mixed loads.  It has a very large voltage range: 40% - 125% of the nominal voltage. The built-in magnetic arc blow-out ensures adequate DC breaking capacity resulting in…
