Flush & PCB mounting sockets

•

  V18 socket – PCB mount

  The V18 is a relay socket for soldering on PCB. The relay will be plugged into the socket, the socket will be soldered on the PCB. There is only one way of connecting the relay to the socket to guarantee correct placement of the relay. Equipped with an integrated retaining clip. To prevent fault relay placement the socket can be equipped with mechanical keying to accept only designated identical keyed…
•

  V26 socket – Crimp terminal, panel mount

  The V26 is a panel mount relay socket with one terminal per relay contact. The wires are crimped on separate crimp contacts A260 for insertion after crimping. To prevent fault relay placement the socket can be equipped with mechanical keying to accept only designated identical keyed relays. (more…)
•

  V3 socket – Soldering terminals, panel mount

  The V3 is a panel / flush mount relay socket for soldering wires onto solder tags. The V3 socket has one terminal per relay contact. The V3 relay socket has no internal connections which makes it highly reliable. To prevent fault relay placement the socket can be equipped with mechanical keying to accept only designated identical keyed relays. (more…)
•

  V31 socket – Faston terminal, panel mount

  The V31 is a panel mount relay socket. The V31 socket has two faston connections per relay contact, so looping/daisy chaining can be done on the socket and no external connector or terminal is needed. To prevent fault relay placement the socket can be equipped with mechanical keying to accept only designated identical keyed relays. Clear UP arrow for correct mounting. (more…)
•

  V32 socket – PCB mount

  The V32 is a relay socket for soldering on PCB. The relay will be plugged into the socket, the socket will be soldered on the PCB. There is only one way of connecting the relay to the socket to guarantee correct placement of the relay. (more…)
•

  V33 socket – Spring clamp terminal, panel mount

  The V33 is a panel/flush mount relay socket. The V33 socket has a base with two highly reliable spring clamp terminals per relay contact, so looping/ daisy chaining can be done on the socket and no external connector or terminal is needed. The spring clamp terminal makes a quick connection possible by pressing the spring with a flat-bladed screwdriver and inserting the stripped wire. Solid and (fine) stranded wires up…
•

  V34 relay socket

  Features Relay sockets with rear M4 screw connections For use with relays in the Mors Smitt D series housing Suits 14 terminal relays Suitable for surface mounting with rear connection Optional flush panel mount adaptor kits Description The V34 socket provides a rear screw connection option to suit a range of Mors Smitt plug in relay types that use the D series housing, including: D series BD series Timers Optional…
•

  V88 socket – Push-in terminal, panel mount 8 pole

  The V88 is a panel/flush mount relay socket. The V88 socket has a base with two highly reliable spring clamp terminals per relay contact, so looping/ daisy chaining can be done on the socket an no external connector or terminal is needed. The spring clamp terminal makes a quick connection possible by pressing the spring with a flat-bladed screwdriver and inserting the stripped wire. Solid and (fine) stranded wires up…
•

  V89 socket – Faston terminal, panel mount 8 pole

  The V89 is a panel mount relay socket. The V89 socket has two faston connections per relay contact, so looping/daisy chaining can be done on the socket and no external connector or terminal is needed. To prevent fault relay placement the socket can be equipped with mechanical keying to accept only designated identical keyed relays. Clear UP arrow for correct mounting. (more…)
•

  V96 socket – Soldering terminals, panel mount, 8 pole

  The V96 is a panel / flush mount relay socket for soldering wires onto solder tags. The V96 socket has one terminal per relay contact. The V96 relay socket has no internal connections which makes it highly reliable. To prevent fault relay placement the socket can be equipped with mechanical keying to accept only designated identical keyed relays. (more…)
•

  V97 socket – Crimp terminal, panel mount, 8 pole

  The V97 is a panel mount relay socket with one terminal per relay contact. The wires are crimped on separate crimp contacts A260 for insertion after crimping. To prevent fault relay placement the socket can be equipped with mechanical keying to accept only designated identical keyed relays. Clear UP arrow for correct mounting. (more…)
